5 Setting up the unit
Recommendation At least 20” [500 mm] away from left side of the
unit so that service work can be performed.
500 mm
/20"
Minimum distance to other units Minimum 14” [350 mm] distance between left
side of the unit and heat sources.
350 mm/
14”
Heat shield To reduce thermo loads to the unit heat shields
can be used (see options).
