6 Electrical connection
Fuse [A]
60 61 62 11 12 21 22
2 AC 208V 50 60
2 AC 240V 50 70
3 AC 208V 30 35 70 60 125 125 200
3 AC 240V 30 40 80 75 150 150 250
3 AC 440V 20 35 30 60 60 100
3 AC 480V 25 40 35 70 70 110
AWG [x]
60 61 62 11 12 21 22
2 AC 208V 8 4
2 AC 240V 8 4
3 AC 208V 12 8 3 4 2 1 4/0
3 AC 240V 12 8 3 4 2 1 3/0
3 AC 440V 14 8 8 4 4 2
3 AC 480V 14 8 8 4 4 3
Maximum permissible tolerance for input voltage (see type label for input voltage) is
within the range of -15% to + 10%.
Use copper wire only for power supply connections.
