Rational CombiMaster Plus User Manual

Domestic technology
97 / 107
Servicing the air filter
Table-top appliance 6 x 2/3 GN
Use a suitable object (coin, screwdriver) to loosen the
air filter by sliding the object into the slot located at the
front-middle and press backwards. This will release
the locking mechanism on the air filter. Pull the filter
downwards at an angle out of the appliance.
Clean the air filter in the dishwasher (not CleanJet®)
and then leave it to dry. If the air filter is still covered in
dirt and residues after the cleaning process, it must be
replaced.
To install the air filter, slide it at an angle from
underneath into the appliance. Press the filter's plastic
housing up until it locks into place.
Air filter no.: 40.04.771
Table-top appliances 6 x 1/1 GN, 6 x 2/1 GN, 10 x
1/1 GN and 10 x 2/1 GN:
Loosen the air filter by pressing the frame on both
roughened surfaces. Tilt the filter down and pull the
entire filter out of the appliance.
Clean the air filter in the dishwasher (not CleanJet
®
!)
and then leave it to dry. If the air filter is still covered in
dirt and residues after the cleaning process, it must be
replaced.
First insert the air filter with the rear hooks into the
holes on the bottom of the appliance and lock them into
place by pressing from below upwards (vice-versa to
remove the filter).
Air filter no.: 40.03.461
Standalone appliances 20 x 1/1 GN and 20 x 2/1
GN:
To replace air filters for standalone appliances
20 x 1/1 GN and 20 x 2/1 GN, please notify your
Rational Service Partner!

Rational CombiMaster Plus Specifications

General

Model	CombiMaster Plus
Manufacturer	Rational
Category	Oven
Cooking modes	Steam, Convection, Combination
Temperature range	30°C to 300°C
Cleaning system	Manual cleaning
Power Consumption	Varies by model
Steam Generator Output	Varies by model
Weight	Varies by model
Dimensions	Varies by model
Control type	Manual
Capacity	10-20 levels (depending on model)
