Rational CombiMaster Plus User Manual

Domestic technology
98 / 107
Replacing the door gasket
The door seal is fitted in a groove on the cooking
cabinet.
- Remove the old gasket from the groove.
- Clean the groove rail.
- Insert new gasket into the groove (moisten the
retaining lips with soapy water).
- The rectangular part of the gasket must be seated
fully in the holding frame.
Press-fit door gasket:
6 x 2/3 GN No. 20.02.549
6 x 1/1 GN No. 20.02.550
6 x 2/1 GN No. 20.02.551
10 x 1/1 GN No. 20.02.552
10 x 2/1 GN No. 20.02.553
20 x 1/1 GN No.: 20.00.398
20 x 2/1 GN No.: 20.00.399
Replacing the lamps
LED lighting
To replace the LED lighting, please contact your authorised RATIONAL Service Partner.
Changing the halogen lamp
First switch off the appliance at the mains.
- Cover the appliance drain in the cooking cabinet.
- Remove the frame with glass and gasket.
- Replace halogen bulb (no.: 3024.0201), do not
touch the bulb with your hands).
- Replace gasket frame as well (no.: 40.00.094).
- Remove the frame with glass and gasket.

Rational CombiMaster Plus Specifications

General

Model	CombiMaster Plus
Manufacturer	Rational
Category	Oven
Cooking modes	Steam, Convection, Combination
Temperature range	30°C to 300°C
Cleaning system	Manual cleaning
Power Consumption	Varies by model
Steam Generator Output	Varies by model
Weight	Varies by model
Dimensions	Varies by model
Control type	Manual
Capacity	10-20 levels (depending on model)
