EN
Page 6 of 91
INSTRUCTION, USE AND
MAINTENANCE MANUAL
KEY (Fig. 1)
1 – Weight holding bridge
2 – Pneumatic chuck
3 – Distance-diameter caliper
4 – Threaded chuck
5 – Protection guard
6 – Pedal brake (for all models)
Chuck open-close pedal (on models with pneu-
matic chuck)
7 – Main switch
8 – External data gauge (standard on some mod-
els)
9 – Monitor
10 – Grippers for weight fitting
11 – Lateral guard
12 – 7-keys keyboard
13 – Pressure ring
14 – Car ring nut (on models with threaded chuck)
15 – Pneumatic locking sleeve (on models with
pneumatic chuck)
16 – Cones + protection cup
17 – Manual caliper
18 – Grippers for weights
19 – Carriages counterweight
20 – Fixed laser unit + LED light (standard on some
models)
21 – Automatic width measuring device unit
(standard on some models)
22 – Off-road vehicle cone D.88 - 132 (standard on
some models)
23 – Wheel protection plate (standard on some
models)
24 – Flange with gauge (standard on some models)
25 – “12 o’clock” laser device (optional)
26 – Ultrasound Run-out (optional)
27 – Ultrasound Run-out with support (optional)
28 – Printer kit (optional)
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.
1297-M058-00
