18.0 TECHNICAL DATA
18.1 Technical electrical data
Max. absorbed voltage (W) 100
Power supply
Voltage (V) 110-230
Phases 1
Frequency
(Hz)
50/60
Rotation speed (rev/min) < 100
18.2 Technical mechanical data
Balancing precision (g) ± 1
Rim width (inches) 1.5 ÷ 22
Rim diameter (inches) 10 ÷ 26 (manually up to 30)
Max. wheel diameter (inches) 43
Cycle time (sec) 6
Sound emission level (dBA) < 70
Max. wheel weight (kg) 70
Recommended air pressure (bar) 8 ÷ 10
Model with
threaded chuck
Model with
pneumatic chuck
Weight (Kg) 145 150
