Press button to select the outer weight to edit.
Press buttons or to increase or decrease
the total weight to be fitted.
THE YELLOW VALUE INDICATES
WHICH VALUE IS ACTIVE AND YOU
ARE EDITING.
THE HIGHER THE CHOSEN
WEIGHTS VALUE IS, THE MORE
THEY WILL BE SPACED.
After choosing the value of the weights to be fitted,
press button to position the wheel for the ap-
plication of the 1st clip weight.
THE TWO GREEN ARROWS INDI-
CATE THAT THE WHEEL IS PROP-
ERLY POSITIONED FOR THE AP-
PLICATION OF THE 1ST WEIGHT.
Fit the clip weight of the chosen value at “12 o'clock” on
the outside of the wheel. Press again button to
position the wheel for the fitting of the 2
nd
clip weight.
Fit the clip weight of the chosen value at “12 o'clock”
on the outside of the wheel. Press button to
highlight the value of the weights to be fitted on the
inside of the wheel.
Repeat the above steps for the weights to be fitted
inside the wheel.
At the end perform again a checking spin to see that
you have applied the weights correctly.
