rav G3.150 - Page 89

EN
Page 89 of 91
WIRING CONNECTION
DIAGRAM
Drawing N°A - Rev. 0 129705533
KEY
1 – Power supply cable L=2000
2 – Wired switch with plug
3 – Cable from switch to transformer
4 – Fuse
5 – Transformer
6 – 90W-380/P power card kit - UL/CSA
7 – DC motor
8 – Motor support ground cable
9 – Wheel position sensor cable
10 – Encoder card
11 – Piezo with front cable
12 – Piezo with cable
13 – Potentiometer with cable
14 – Optical line card
15 – Cable for pedal micro (on models with pneumatic chuck)
16 – MV15 limit switch (on models with pneumatic chuck)
17 – Cable for wheel micro protection
18 – MV15 limit switch
19 – Cable for SV-0 solenoid valve (on models with pneumatic chuck)
20 – Cable for solenoid valve SV-C (on models with pneumatic chuck)
21 – Fitting of solenoid valve (on models with pneumatic chuck)
22 – 24V power supply cable + serial
23 – Monitor card kit
24 – Touch screen monitor 20” HDMI
25 – Push-button panel with 7 keys cables
26 – 7-keys keyboard
27 – LED light (standard on some models and on GAR308)
28 – Line laser (with cable) (standard on some models and on GAR308)
29 – Width potentiometer extension cable (on GAR303, GAR305, GAR307)
30 – Width cables (on GAR303, GAR305)
31 – Potentiometer with shielded cable (on GAR307)
32 – Run-out push button cables (on GAR303)
33 – Run-out keyboard extension cable (on GAR303)
34 – Push-button panel with 1 key (on GAR303)
35 – Ultrasounds sensor extension cable (on GAR303)
36 – Potentiometer with cable (on GAR303)
37 – Wiring diagram GAR334, GAR335
38 – Ultrasounds sensor extension cable (for GAR315, GAR316, GAR337)
39 – Run-out card at 100 RPM (for GAR315, GAR316, GAR337)
40 – Cable for ultrasounds (for GAR315, GAR316, GAR337)
41 – Ultrasounds sensor (for GAR315, GAR316, GAR337)
42 – CAN to BTH & RS232 (for GAR329)
43 – 2-wires cable (for GAR329)
44 – Ultrasounds sensor card (for wheel balancers with automatic width or GAR332)
45 – Width card cable assembly (for wheel balancers with automatic width or GAR332)
46 – Extension cable assembly (for wheel balancers with automatic width or GAR332)
47 – Printer kit
48 – Power supply cable
49 – Cable from transformer to power supply
50 – Touch screen monitor 19”
51 – HDMI-HDMI cable
52 – Cable USB/A - USB/B
53 – Monitor SBC kit
G3.150 - GP3.150 - G3.150S - GP3.150S - G3.150WS - GP3.150WS - G3.150WSPLUS - GP3.150WSPLUS - G3.150SA - G3.150WSA
RAVAGLIOLI S.p.A.
1297-M058-00
