52
7300-M009-0_R
10. OPERATIONAL DIAGRAMS
10.1 Wiring diagram
With reference to Fig. 21-22-23:
M Motor
IG Main inverter
I Motor control inverter
P1 Clockwise motor control potentiometer
FC1 Anticlockwise motor control microswitch
10.2 Pneumatic diagram
With reference to Fig. 24-25-26-27-28:
A Air feeding joint
B1 Separating filter
B3 Lubricator
C Rotating distributor
D Silencer
E1 Beader control distributor (single effect cylinder)
E2 Beader control distributor (double effect cylinder)
E3 Chucking table jaws control distributor
E4 Column turnover control distributor
F Inflating gun with manometer
H1 Single effect beading cylinder
H2 Double effect beading cylinder
H3 Chucking table cylinder
H4 Column turnover cylinder
H7 Head locking cylinder
I Flow regulator
K 5-way distributor
M Reservoir
N Inflating/tubeless inflating control distributor
O2 Max. pressure valve (pressure set to 11 bars)
P Deflating valve
Q Manometer
R Inflating valve (tubeless inflating)
T Tubeless inflating air lances
U Inflating air lance
V Head locking control distributor
Y Inflating head
W1 Inflating pressure limiting valve with deflating valve (pressure setting: 3.5 bar)
W2 Inflating pressure limiting valve (pressure setting: 3.5 bar)
11. DECLARATION OF CONFORMITY
The validity of the Conformity Declaration enclosed to this manual is also extended to products and/or
devices the machine model object of the Conformity Declaration can be equipped with.
12. IDENTIFICATION PLATE
With reference to Fig.29:
A Manufacteur
B Serial number
C Year of manufacteure
D Model
CAUTION: Do not tamper with, carve, change or remove the identification plate; do not cover it with panels,
etc., since it must always be visible.
Said plate must always be kept clean.
WARNING: Should the plate be accidentally damaged (removed from the machine, damaged or even partially
illegible) inform immediately the manufacturer.
