INSTRUCTION, USE AND
MAINTENANCE MANUAL
GB
Page 3 of 60
RAVAGLIOLI S.p.A.
7300-M018-2_R
G8945.26 - G8945IT.26 - G8945V.26 - G8945ITV.26 - G8945V.26S - G8945ITV.26S - G8945D.26 - G8945ITD.26 - G8945D.26S - G8945ITD.26S
Table E - Pneumatic diagram
(G8945.26 - G8945D.26 -
G8945V.26) ______________________ 47
Table F - Pneumatic diagram
(G8945IT.26 - G8945ITD.26 -
G8945ITV.26) ____________________ 50
Table G - Pneumatic diagram
(G8945V.26S - G8945D.26S) _____ 53
Table H - Pneumatic diagram
(G8945ITV.26S - G8945ITD.26S) _ 56
Table I - Lifting device pneumatic
diagram ________________________ 59
20.0 LIST OF COMPONENTS
