Instruction manual
RAVAGLIOLI S.p.A.
RAVTD1760 WS – RAVTD1780 WS
Code M0197 - rev.1.0
(11/2010)
Page 8/52
RAVAGLIOLI S.p.A. - Via I° Maggio, n° 3 (Pontecchio Marconi)
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 E-mail: rav@ravaglioli.com
BATTERY
COMPARTMENT
3.6.1 Front Detectors
Figure 2
3.6.2 Rear Detectors RAV TD1780WS
Figure 3
3.6.3 Rear Detectors RAV TD1760WS
Figure 4
DETECTOR KEYPAD
(see par. 3.6.4 on page 10)
BATTERY
COMPARTMENT
GREEN LED indicating that
detector is under charge
RED LED indicating that detector
is on
DETECTOR PIN LOCKING
KNOB
LED for tolerance indication
(see par. 3.6.4 on page 10)
GREEN LED indicating that detector is
under charge
RED LED indicating that detector is on
DETECTOR KEYPAD
(see par. 3.6.4 on page 10)
LED indicating Levelling and tolerance
(see par. 3.6.4 on page 10)
DETECTOR PIN LOCKING KNOB
BATTERY
COMPARTMENT
DETECTOR KEYPAD
(see par. 3.6.4 on page 10)
GREEN LED indicating that detector
is under charge
RED LED indicating that detector is
on
