Instruction manual
RAVAGLIOLI S.p.A.
RAVTD1760 WS – RAVTD1780 WS
Code M0197 - rev.1.0
(11/2010)
RAVAGLIOLI S.p.A. - Via I° Maggio, n° 3 (Pontecchio Marconi)
Page 17/52
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 E-mail: rav@ravaglioli.com
7.1 DATABASE Groups Configuration
Select "GROUPS CONFIGURATION" from programme configuration page, as explained in par.
7 on page 16.
You can edit system parameters, database profile, and specify which parts are fitted on the
machine, and parts type as well.
Figure 17
DETECTOR
KEYPAD
PC KEYBOARD DESCRIPTION
It goes back to the start
configuration page.
(par.8.1 on page19)
It moves selection up.
It moves selection down.
It confirms selection.
Select “DATABASE” option, and confirm. The following screen will be displayed:
Figure 18
