Figure 39
“STOP” is displayed for approx. three seconds, which is enough for the programme to acquire
measurement readings.
Figure 40
Position reference sensor again with the end up, almost in the "target" position reached in
Figure 48 and, when finished, press central key to confirm.
Figure 41
Reference
sensor
horizontal
position
Reposition
the reference
sensor as
"target".
