Instruction manual
RAVAGLIOLI S.p.A.
RAVTD1760 WS – RAVTD1780 WS
Code M0197 - rev.1.0
(11/2010)
Page 12/52
RAVAGLIOLI S.p.A. - Via I° Maggio, n° 3 (Pontecchio Marconi)
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 E-mail: rav@ravaglioli.com
3.8 Rotating Plates
3.8.1 Rotating Plates S110A7
Rotating plates S110A7 have a disc diameter of 250 mm, and a loading capacity of 1,000 kg.
Figure 10
3.8.2 Electronic Rotating Plates Connected to Detectors with STDS43 Via Radio
Transmission
Electronic rotating plates STDA43 have a 300 mm anti-slip disc, and a loading capacity of
1,250 kg.
They require a low rotating torque and, as they feature and encoder, provide a high
resolution.
Figure 11
UPPER PLATE WITH ANTI-
SLIP DISC
GRADUATED ROD
GRADUAL INDICATOR
UPPER PLATE WITH ANTI-
SLIP DISC
PLATE RETAINER
PLATE RETAINER
CABLE FOR CONNECTION TO
FRONT DETECTORS
(see par. 3.6.1 on page 9)
