8.14 Printout of Measurements taken
By selecting the following key from the customer data entry page, the following
screen will be displayed:
Figure 54
DETECTOR
KEYPAD
PC KEYBOARD DESCRIPTION
Repeat steering procedure.
(par. 8.8 on page 34)
It stores the carried out
diagnosis inside a special
“customer database” so as to
allow test later displaying
(par. 8.13 on page 38)
It displays a print preview of
the test carried out
(par. 8.14 on page 39)
It goes back to start page
without storing test
Figure 55
Vehicle and
customer data
entry
