Important: In addition to the Gen II wiring kit components listed above, an implement extension tee cable is
required for the operation of the PowerGlide Plus AutoBoom system. For available cables and ordering
information, contact your local Raven dealer.
Install the PowerGlide Plus Hydraulic System
TABLE 5. Gen II PowerGlide Plus Wiring Kit (P/N 117-5130-001)
Picture Item Description Part Number Qty.
Not Pictured Manual - AutoBoom Calibration & Operation 016-0130-062 1
Node - PowerGlide Plus AutoBoom 063-0130-010 1
Cable - PowerGlide Plus/UltraGlide with
CAN/Power Tee AutoBoom
115-0230-085 1
WARNING
The machine must remain stationary and
switched off, with the booms unfolded and
supported, during installation or maintenance.
CAUTION
When installing AutoBoom hydraulics or
performing diagnostics, maintenance, or routine
service, ensure precautions are taken to
prevent any foreign material from being
introduced into the machine’s hydraulic system.
Objects or materials that are able to bypass the
machine’s hydraulic filtration system will reduce
performance and possibly cause damage to the
AutoBoom hydraulic valve.
