Raven CR7 - Load Field and Create New Job in the Field

PAGE 15/34 | User manual | 016-8000-017EN | Rev. B
START FIELD AND JOB | CR7 | QUICKSTART STEERING MANUAL
LOAD FIELD AND CREATE NEW JOB IN THE FIELD
#
Description
Figure
31
Press the blue arrow on the side of the
screen in Maps.
Select the Field.
32
Press New Job if a New Job is started. Select
one of the existing Job’s underneath to open
and restart an existing Job.
33
The name of the mounted implement is
shown.
In case this is not correct, go back to step
#19.
In case this is correct, press next step.
34
The Job will open. Proceed to step #35.
