CREATE AND SHIFT-NUDGE AB LINE | CR7 | QUICKSTART STEERING MANUAL
PAGE 16/34 | User manual | 016-8000-017EN | Rev. B
Raven Industries Inc.
4 CREATE AND SHIFT-NUDGE AB LINE
CREATE AB-LINE
#
Description
Figure
35
Press on the button with the arrow on the
right side of the screen.
36
Press on the type of line that needs to be
created (for this example we use the Straight
AB).
37
In the beginning of the line and the
beginning of the field, press on ‘Set A’.
38
Drive straight forward to the other side of
the field.
