Raven CR7 - CRX Interface Navigation; Home Screen Layout

PAGE 17/34 | User manual | 016-8000-017EN | Rev. B
CREATE AND SHIFT-NUDGE AB LINE | CR7 | QUICKSTART STEERING MANUAL
39
Once the distance is big enough (after 10m)
the line will be created and Autosteer can be
activated.
It is more accurate to enter ‘Set B’ on the
other side of the field.
Press ‘Set B’.
40
Press the green checkmark.
41
Press on the edit button of the AB line to
give it a name.
42
Give the AB line a name so it will be easy to
reload the line another time.
