DRIVING DIRECTION | CR7 | QUICKSTART STEERING MANUAL
5 DRIVING DIRECTION
#
Description
Figure
52
When driving forward the, the arrow must be
shown as in the next screen (just a blue
arrow without a red arrow in front of it).
53
When the big red arrow is in front of the
blue arrow, the system thinks the machine is
driving backwards.
In this case, press the red arrow to change
the driving direction.
