Raven CR7 User Manual

CREATE AND SHIFT-NUDGE AB LINE | CR7 | QUICKSTART STEERING MANUAL
PAGE 20/34 | User manual | 016-8000-017EN | Rev. B
Raven Industries Inc.
50
Press on the arrow to nudge the line with the
preset distances per arrow.
51
Press the ‘Center Line’ widget to shift the
closest Guidance Line underneath the
machine.
The closest line is now on the current
position. Autosteer can now be activated in
the line direction on the current position.
If the widget is not in the Job screen,
proceed to chapter 7.
