PAGE 19/34 | User manual | 016-8000-017EN | Rev. B
CREATE AND SHIFT-NUDGE AB LINE | CR7 | QUICKSTART STEERING MANUAL
SHIFT – NUDGE AB LINE
Press on the ‘Shift Line’ widget (see figure). If
the widget is not in the screen, proceed to
step #59 and add the widget before
continuing.
After pressing, the arrows on the right and
left side appears next to the widget.
Press and hold the widget (min. 3 sec) to
configure the widget.
After pressing and holding the widget, press
the ‘expand’ button to configure the arrows.
Enther the Presets per arrow for the line
nudging.
Press the green checkmark to go back to the
Job.
