CREATE AND LOAD A BOUNDARY (SCOUT FEATURE) | CR7 | QUICKSTART STEERING MANUAL
PAGE 22/34 | User manual | 016-8000-017EN | Rev. B
Raven Industries Inc.
6 CREATE AND LOAD A BOUNDARY (SCOUT FEATURE)
#
Description
Figure
54
When in a job, press on the button with the
telescope (on the right side of the screen).
55
To load an existing boundary, press on the
existing feature (when they are created, they
are saved and can be loaded in the white list
underneath.
To create a boundary, press on the + button.
56
To record a new boundary, press on Field
Boundary.
57
Select whether the zone needs to be
recorded in the center, on the left or on the
right side of the selected implement.
Press play to start the recording and start
driving around the field.
