19
9. VALVE CAL
To display current VALVE CAL setting, depress dey labled for 5
seconds. VALVE CAL number will show in DATA display.
10. CONTROL VALVE DELAY
Depress key labelled for 5 seconds. "dLAY" will be displayed.
The Control Valve Delay number is a 4 digit number. The first didgit in the Control
Valve Delay number represents the time (in seconds) between when the booms are
turned ON and when the Console actually begins to control the flow rate. A value
of 1-9 means a delay of 1-9 seconds respectively, a value of 0 means no delay.
The remaining 3 digits are always zero. The Control Valve Delay feature only
operates when the booms are toggled OFF or ON in intervals of 30 seconds or less.
11. SEQUENCE TO ACTIVATE DATA-LOCK
The DATA-LOCK feature prohibits the entry of data without first entering an
activated code number. The code number may be up to 4 digits long. The code number
may be cleared by changing the activated code from its existing number to "0",
or by resetting the Console (SEE INITIAL CONSOLE PROGRAMMING).
NOTE:NOTE:
NOTE:NOTE:
NOTE: If the DATA-LOCK feature is not desired, skip Step 10.
1)1)
1)1)
1) Depress
for 5 seconds, a new code indicator message of "nEu.l " will appear.
2)2)
2)2)
2) Enter a desired number code within 15 seconds.
EXAMPLE:EXAMPLE:
EXAMPLE:EXAMPLE:
EXAMPLE: For code number 1234: Depress
and .
12. SEQUENCE TO CHANGE DATA-LOCK
1)1)
1)1)
1) Depress for 5 seconds, an old code indicator message of "oLd " will appear.
2)2)
2)2)
2) Enter the existing number code within 15 seconds.
3)3)
3)3)
3) A new code indicator message of "nEu.l " will appear.
4)4)
4)4)
4) Enter the new number code within 15 seconds.
EXAMPLE:EXAMPLE:
EXAMPLE:EXAMPLE:
EXAMPLE: For code number 4321: Depress
and .
X 0 0 0
Control Valve
Delay Digit
To Next Page
