2. OTHER DISPLAY FEATURES
See Appendix 9 for detailed outline of each Console key and what features are
located under them.
1)1)
1)1)
1) To display the set operating modes for units of measure (US, SI, TU), speed sensor
type (SP1, SP2), and valve type (C-Sd, C-FC), depress
for 5 seconds and
continue holding. DATA display will toggle thru selections until key is released.
2)2)
2)2)
2) To display TOTAL AREA covered, depress key labelled
.
To "zero out" this total at any time, enter a "0" in this key.
3)3)
3)3)
3) To display TOTAL VOLUME sprayed, depress key labelled
.
To "zero out" this total at any time, enter a "0" in this key.
4)4)
4)4)
4) To display speed in MPH [km/h], depress key labelled
.
5)5)
5)5)
5) To display DISTANCE in feet [m] traveled, depress key labelled
.
To "zero out" this total at any time, enter a "0" in this key.
6)6)
6)6)
6) To display actual application flow rate in GAL/MIN [li/min], place MASTER switch
in ON position and depress key labelled
.
To display target application flow rate, place MASTER switch to OFF and depress
key labelled
.
To display the volume/minute being applied, depress key labelled
for 5
seconds.
7)7)
7)7)
7) To display current VALVE CAL setting, depress key labelled
for 5 seconds.
VALVE CAL number will show in DATA display.
8)8)
8)8)
8) To view any of the set calibration numbers, depress the corresponding calibration
keys.
