1. INITIAL CONSOLE PROGRAMMING
When you first turn on Console power after all installation procedures have been
completed, the Console will display "US" in the display window. This means you
must "calibrate", or program, the Console before it can be operated. This is a
one-time operation which does not have to be repeated. Turning OFF the power switch
does not affect the Console memory. All data is retained.
IMPORTANT:IMPORTANT:
IMPORTANT:IMPORTANT:
IMPORTANT: If an entry selection error is made during Steps 1-6, place the
AUTO/MAN/OFF switch to the OFF position. Depress the
key
and hold while placing the AUTO/MAN/OFF switch to AUTO or MAN. This
will "reset" the Console.
The following steps must be followed:
1)1)
1)1)
1) Display US (acres), SI [hectares], or TU {1000 sq. ft.}.
a)a)
a)a)
a) Depressing momentarily
steps the display from US to SI.
b)b)
b)b)
b) Depressing momentarily
steps the display from SI to TU.
c)c)
c)c)
c) Depressing momentarily
steps the display from TU to US.
2)2)
2)2)
2) Selecting US, SI, or TU.
a)a)
a)a)
a) To select US, SI, or TU, step
until the desired code is displayed.
b)b)
b)b)
b) Momentarily depress
. The display will now display SP1.
3)3)
3)3)
3) Display SP1 (wheel drives, etc.) or SP2 (radar).
a)a)
a)a)
a) Depressing momentarily
steps the display from SP1 to SP2.
b)b)
b)b)
b) Depressing momentarily
steps the display from SP2 to SP1.
4)4)
4)4)
4) Selecting SP1 or SP2.
a)a)
a)a)
a) To select SP1 or SP2, step with
until desired code is displayed.
b)b)
b)b)
b) Momentarily depress
. The display will now display C-Sd.
