Chapter 4
26 SCS 4000/5000 Series™ Installation & Operation Manual
FIGURE 5. Chassis Cable Platform Example (SCS 4000/4070/5000 Consoles Only)
Raven CAN Switch Box
(For use with Multiple
Applications)
To
Node #2
(Kit)
CAN/
Power
Tee
CAN/Power
Tee
Dust Cap
CAN
Terminator
HITCH
CONNECTION
*Connect if using
internal GPS Source*
To
Node #1
(Kit)
To Field Computer
SmarTrax
Tee Cable
(Optional)
To SmarTrax
Node Cabling (Kit)
CANbus
Switched
Power Output
*Internal GPS
Receiver Output*
*GPS Receiver/
DGPS*
COM 3
COM 2
Switched
Power Output
GPS
Speed Out
Envizio Pro (II)/Viper Pro
Chassis Cable Interface
5 Amp Console Power
CAN
Terminator
CAN
Remote
Switch
Chassis
Cable
To Cab Cable
Cab High
Current
Power (15 A)
System Logic
Power (10 A)
30 A
30 A
Battery
Connections
Battery
Connections
To Cab
Cable
SmarTrax Only
Chassis Cable
Remote
Switch
Field Hub RTK
Corrections
Field Hub Power
Cab High Current
Power (15 A)
Console Logic
Power (10 A)
To SCS 5000
SCS 5000
Chassis Cable Interface
COM 1
Switched
Power
Output
CANbus
5 Amp
Console
Power
To Chassis
Cable
To Cruizer II
To Port ‘A
To ‘CAN’ Port
Power
To CAN
Terminator
Cruizer II
Chassis Cable Interface
To Cruizer II
or
or
or
To
Chassis
Cable
To
Chassis
Cable
To
Chassis
Cable
5 Amp
Console
Power
5 Amp
Console
Power
To CAN
Terminator
Power
To PortA
To ‘CAN’ Port
To PortB
In-Cabin
Harness/Cabling
Implement/
External Calbing
