Raven SCS 5000 User Manual

Manual No. 016-0159-925 Rev. F 5
Introduction
SCS 4000/5000 Series Console Feature Overview
Display Area
Each of the SCS 4000/5000 Series consoles feature an easy to read, backlit LCD display. This area displays
application and user interface information such as speed, PSI, calibration and function data, rate of application,
control mode (AUTO/MAN), percent of compact flash card used (only on SCS 4400/4600 consoles), and boom
status.
Keypad
The SCS 4000/5000 Series consoles feature a push button keypad with large, clearly marked buttons for easy
user interface.
Note: The initial programming sequence must be completed before the SCS console can be operated
normally. Calibration values must also be programmed on the calibration screens accessed
through keys 3 through 7.
Serial Number
The part number, serial number, and hardware revision letter for
each of the SCS 4000/5000 Series consoles may be found on the
console label on the back of the SCS console.
Please have this information available when contacting customer
support.
Enter
CE
(Clear Entry)
Power
Auto/Manual
xxxxxxxxxxx
xxxxxxxxxx
-
xxxxxxx
