Manual No. 016-0159-925 Rev. F 91
Serial Interface & Data String Formats
Data Strings:
• $R114-,D1,<total_area_1>,<total_area_2>,<total_area_3>,<total_area_4>,<total_area_5>,<field_area_1>,
<field_area_2>,<field_area_3>,<field_area_4>,<field_area_5><CR><LF>
• $R114-,D2,<total_volume_1>,<total_volume_2>,<total_volume_3>,<total_volume_4>,<total_volume_5>,
<field_volume_1>,<field_volume_2>, <field_volume_3>,<field_volume_4>,<field_volume_5><CR><LF>
• $R114-,D3,<tank_1_volume>,<tank_2_volume>,<tank_3_volume>,<tank_4_volume>,<tank_5_volume>,
<miles/km>,<feet/meters><CR><LF>
Actual Rate:
$R1
14-,AR,<actual_rate_1>,<actua
l_rate_2>,<a
ctual_rate_3>,<actual_rate_4>,<actual_rate_5><CR><LF>
Time/Date:
$R114-,TD,<hr:min>,<month/day/year>,<field_reference><CR><LF>
SCS 4400/4600 Console to Remote
Computer
All console output strings begin with $R164-, the $R indicates a Raven communication string, 164 are the last
three digits of the SCS 4400/4600 program number and “-” denotes the software revision letter.
Calibration Strings:
• $R164-,C1,<switch_byte_1>,<switch_byte_2>,<boom_1_cal>,<boom_2_cal>,<boom_3_cal>,
<boom_4_cal>, <boom_5_cal>,<boom_6_cal>,<boom_7_cal>,<boom_8_cal>,<boom_9_cal>,
<boom_10_cal>,<speed_cal> <CR><LF>
• $R164-,C2,<meter_1_cal>,<meter_2_cal>,<meter_3_cal>,<meter_4_cal>,<meter_5_cal>,
<spreader_constant_1>, <spreader_constant_2>,<spreader_constant_3>,<spreader_constant_4>,
<spreader_constant_5><CR><LF>
• $R164-,C3,<valve_cal>,<valve_2_cal>,<valve_3_cal>,<valve_4_cal>,<valve_5_cal>,<rate_1_cal>,
<rate_2_cal>,<rate_3_cal>,<rate_4_cal>,<rate_5_cal><CR><LF>
Note: If prod auto and manual are both zero, the product is off. For switch Byte Bits: 0 = Off and 1 = On.
Bit Switch Byte 1 Switch Byte 2 Switch Byte 3
0 boom 1 boom 8 prod 3 auto
1 boom 2 boom 9 prod 3 manual
2 boom 3 boom 10 prod 4 auto
3 boom 4 prod 1 auto prod 4 manual
4 boom 5 prod 1 manual prod 5 auto
5 boom 6 prod 2 auto prod 5 manual
6 boom 7 prod 2 manual 0
71 1 1
