Manual No. 016-0159-925 Rev. F v
Calibration Reference Sheet
Record the settings and calibration values used when programming the SCS console and keep this sheet for
future reference or when contacting a service technician.
Circle the setting selected on the console for the following options:
Write down the selected settings for each configured control channel in the spaces provided:
Write down the calculated calibration values in the spaces provided:
Edit Mode
During normal operation of the SCS console, pressing the calibration keys will access a calibration screen. The
operator must use the Edit mode to program numerical values into the SCS console. To enter Edit mode:
1. Press the ENTER key. The default or existing value will be cleared and the screen will display an “E” on the
far right side of the screen.
2. Key in the value to replace the existing value. For example, press “2” “1” “2” “3” to enter a value of 2123.
3. Press the ENTER key to accept the keyed value and return to normal operation.
Note: During the initial console programming, pressing ENTER accepts the keyed value and advances
to the next calibration screen.
Units
US (Acres) SI (Hectares) Turf (1000 Square Feet)
Speed
Sensor
SP1 (Wheel Speed) SP2 (Radar)
Speed Cal
Control Channel
1
Control Channel
2
Control Channel
3
Control Channel
4
Control Channel
5
Control
Type
Valve Type
Boom Widths
(Boom Cal)
Meter Cal Rate Cal Valve Cal
Volume in
Tank/Bin
1. 1. 1. 1. 1.
2. 2. 2. 2. 2.
3. 3. 3. 3. 3.
4. 4. 4. 4. 4.
5. 5. 5. 5. 5.
6.
7.
8.
9.
10.
To Next Page
