Raven SCS 661 User Manual

9
5. MOUNTING THE HYDRAULIC CONTROL VALVE (Granular
Applications)
1) Refer to Figures 6,7, 8 & 9 for typical placement of the Hydraulic Control Valve.
2) Valve is to be mounted with motor in the upright position.
PNEUMATIC SYSTEM
SPINNER SYSTEM
CLOSED HYDRAULIC SYSTEM (VARIABLE DISP. PUMP)
FIGURE 9FIGURE 8
FIGURE 7 FIGURE 6
OPEN HYDRAULIC SYSTEM (FIXED DISP. PUMP)
CLOSED HYDRAULIC SYSTEM (VARIABLE DISP. PUMP)
OPEN HYDRAULIC SYSTEM (FIXED DISP. PUMP)
