CONSOLE CALIBRATION
1. CALCULATING “BOOM CAL”
Calculate the width of each boom in inches (cm) by multiplying the number of tips time the spacing.
Write these boom widths down for future reference when programming the Console.
2. BOOM CALIBRATION
Definition of Boom Calibration keys for a Boom system.
Depressing this key, displays selected boom number in DATA display.
EXAMPLE: Left Boom will be displayed as b-01, and Right Boom will be displayed as
b-10 if all 10 Booms are used.
Depressing this key after selecting BOOM CAL, changes the boom number.
EXAMPLE: b-01 will change to b-02.
Depressing this key after selecting BOOM CAL, changes the boom number.
EXAMPLE: b-02 will change to b-01.
Entering Boom Data:
1. Select desired boom number.
2. Enter boom length as detailed under CALCULATING “BOOM CAL” section.
3. If a boom is not used, enter a “0” for that length.
BOON 1 - BLACK
BOOM 2 - BROWN
BOOM 3 - BLUE
BOOM 4 - BLK/WHT
BOOM 5 - BRN/WHT
BOOM 6 - BLU/WHT
BOOM 7 - WHT/BLK
BOOM 8 - WHT/BRN
BOOM 9 - WHT/BLU
BOOM 10- PINK
