RG55 Operation • Service • Maintenance
30
Operation
00-02-0839 - 5 - 2012-09-21
Menu
Item
Stored
Faults
The Stored Faults (Stored FLTS)
menu shows the SPN, FMI, and
OC for any stored faults. A
message is sent to the ECU, and
the ECU responds with what is in
history.
If there are no stored faults, you
will see this:
Use the Up & Down
arrows to scroll through
the list if there is more
than one stored fault.
To return to the Main
menu press the Up &
Down arrows
simultaneously and
release.
Set Units
The Set Units Config menu will
allow the user to select between
the following unit settings:
English
Metric kPa
Metric BAR
Exit
An asterisk to the right of a setting
indicates it is the current setting.
To enter the Set Units
menu, momentarily press
both arrows and release.
Scroll through the options
using the Down arrow.
Choose a unit by
momentarily pressing the
Up/Down arrows. An
asterisk displays at the
right.
To leave this menu, scroll
down to EXIT, press both
arrows and release.
To Next Page
