RG55 Operation • Service • Maintenance
32
Operation
00-02-0839 - 7 - 2012-09-21
Menu
Item
Set Tier 4
Auto – Automatically displays all
Tier 4 information (symbols) from
the CAN and allows for Auto
Regeneration of a Tier 4 engine
through CAN messaging.
Request – Sends a request to the
ECU to perform a regeneration.
Inhibit – Sends a message to the
ECU to prevent a regeneration
from occurring.
None – Not sending any Tier 4
messages.
Exit – Return to the Main menu.
Momentarily press the Up
& Down arrows to reach
the Tier 4 menu. Select
and set a Tier 4 choice by
pressing the Up/Down
arrows. An asterisk
shows next to the
selection.
Backlight
The Backlight menu allows you
to select the desired backlight
level. The range is 0-100% and it
changes in 5% increments.
This value also broadcasts a CAN
message that can set the
backlights on optional PVCAN
gauges in the panel to the same
intensity.
Pressing the Up/Down
buttons at the same will
toggle into and out of the
adjustment screen.
