RG55R Operation • Service • Maintenance
62
SENSOR- TEMP
& PRESSURE GM
FUEL FILTER
FUEL PUMP
803433
803432
802495
FUEL TANK
NOTE: CUT 730043 FUEL LINE
TO LENGTH AS NEEDED
9"
10"
71"
8"
22"
ENGINE
805776
Fuel System Assembly 38605 Rev B
