7. Retighten the thread. 8. Reconnect the air
assist hose.
8.3.4 Mirror
Caution
Make sure that you do not touch the mirror with your fingers, since this would greatly reduce the
service life of the mirror.
Do not touch the mirror with your fingers or with tools, and never use a cleaning tissue twice, as
the surface could easily be scratched.
Cleaning mirror #3 on the working head
1. Unscrew the two
screws by hand.
2. Loosen the mirror by
wiggling it slightly.
3. Remove mirror. 4. Clean the mirror
carefully.
ENGLISH (Translation)
07/2021
64 / 83
