8058 R400 – Technical Specifications
Mechanics
Working area
1030 mm x 630 mm (40.55 x 24.8 inches)
Loading area
1130 mm x 690 mm (44.45 x 27.17 inches)
Work piece table
Aluminum cutting grid table
Software controlled Z-axis; max. Z-height 200 mm (7.87 inches)
Z-height
200 mm (7.87 inches)
Max. engraving speed
1 m/sec. (39.37 in/sec.)
Acceleration
10m/s² (393 in/sec²)
Max. cutting speed
0.5 m/sec. (19.68 in/sec.)
Motor
Stepper motors
Optical elements
lens air-flushed for soil-protection
Lens
2.0"
Max. material load
Max. 20 kg
Software
Rayjet® Manager printer driver, Rayjet® Manager laser software
Compatible with standard graphic and CAD software like Corel Draw,
Adobe Illustrator, …
Features standard
Features standard
RayPack Technology™, kill and key switch, LED light, electrical Z-axis,
power potentiometer for machine control panel, air cooled optics, laser
pointer (655nm, <0,99mWcw), coaxial air assist (without pump), 2.0”
lens, air-assist nozzles (Ø3mm and Ø7 mm), aluminum cutting grid ta-
ble, sealed CO
2
DC laser source water-cooled integrated, water chiller,
laser class 2, CE certification
Options
Optional features
Rotary attachment, external pump for air assist, aluminum slat cutting
table, 4.0" lens, exhaust system
Control System
Laser power
Adjustable from 0-100%
Hardware interface
USB 2.0
Laser Equipment
Laser source
Sealed CO
2
DC laser source water-cooled
Laser power: 60 W - 100 W
Water chiller
16 l/min
Dimensions & weight
Machine dimensions (Width x Depth x
Height)
1550 mm x 1080 mm x 1080 mm (61.02 x 42.52 x 42.52 inches)
Weight
Approx. 300 kg
Ambient conditions
Mandatory ambient temperature 59° to 77° F or +15° to +25° C
Humidity 40% to max. 70%, not condensing
Dust free environment (2
nd
degree according to IEC 60947-1)
