3.1Productoverview—AIS350
AIS350 R e ce iver
S ta tus
US B
P WR/Da ta S T
ng
VHF ANT
D12 126 -1
TheAIS350isareceive-onlyAISunitthatusesdigitalradiosignals
toreceive'real-time'informationfromothervessels,landbase
stations,oraidtonavigation(AToNs)stationsequippedwithClass
AorClassBAIStransceivers.
Thisinformationisusedtoidentifyandtrackvesselsinthe
surroundingareaandtoprovidefast,automaticandaccurate
collisionavoidancedata.
3.2Planningtheinstallation
Installationchecklist
Installationincludesthefollowingactivities:
InstallationTask
1Planyourinstallation.
2
Obtainallrequiredequipmentandtools.
3Mountthesystemcomponents.
4Routeallcables.
5
Drillcableandmountingholes.
6Makeallconnectionstoequipment.
7
Secureallequipmentinplace.
8
Completethepost-installationcheck.
Schematicdiagram
Aschematicdiagramisanessentialpartofplanninganyinstallation.
Itisalsousefulforanyfutureadditionsormaintenanceofthe
system.Thediagramshouldinclude:
•Locationofallcomponents.
•Connectors,cabletypes,routesandlengths.
