12.13Scannerset-upmenuoptions
TheScannerSet-upmenuenablesyoutoconguretheperformanceandbehaviorofyourradarscanner.
FunctionDescriptionOptions
TimedTransmitSet-up
Thismenuitemcontainsasub-menuthatenablesyoutoadjustthetimedtransmit
options:
•TimedTransmit
•TransmitPeriod
•StandbyPeriod
TimedTransmit
•On
•Off
TransmitPeriod
•10Scans
•20Scans
•30Scans
StandbyPeriod
•3minutes
•5minutes
•10minutes
•15minutes
TuneAdjust
Thismenuitemallowsyoutonetunetheradarscanner’sreceiverformaximum
returnsonthedisplay.RaymarinerecommendsthatthisfunctionissettoAuto.
IfyousetthisfunctiontoManualandadjustthesettingshortlyafterpowering
uptheradarscanner,youshouldadjustitagainapproximately10minutesafter
poweringupthescanner,astherequiredsettingwillchangeafterthemagnetron
haswarmedup.
Man
•Auto
•Man0%—100%
EBLReferenceThemeasurementpointusedforreferencewhenmeasuringdistancesusing
ElectronicBearingLines(EBLs)andrangeringsinthechartapplication.The
optionsareRelativetoshipsheadingorreferencedtothecompassisdegrees
Magnetic—TrueasselectedinBearingMode.
•Relative
•Mag-True
SeaClutterCurveThismenuitemallowsyoutoadjusttheSeaClutter—radarechoesfromwaves
canmakeitdifculttodetectrealtargets.Theseechoesareknownas“seaclutter”.
Severalfactorscanaffectthelevelofclutteryousee,includingtheweatherand
seaconditions,andthemountingheightoftheradar.Theseacluttercurvesetting
adjuststheradar’ssensitivitytoseaclutter.Thesteepestsettingforthecurveis
1,andthemostshallowsettingis8.
•AdjustCurve(1to8)
ScannerSpeedSuperHDopenarrayradarswithsoftwareversion3.23oraboveorHDdigital
radomessupportmultiplescanspeeds:
•24RPM
•48RPM
ScannerSpeed
•24RPM
•Auto—hisoptionautomatically
switchesbetweenthe24RPMand48
RPMscanspeedsasappropriate.
AdvancedSet-upThismenuitemcontainsasub-menuthatenablesyoutoadjustthefollowing
options:
•BearingAlignment
•DisplayTiming
•MainBangSuppression
•TunePreset
•STCPreset—Non-HDDigitalradomesonly
•ResetAdvanced
BearingAlignment
•-180º—179.5º
DisplayTiming
•0.415nm—selectedrange
MainBangSuppression
•On
•Off
TunePreset
•0—255
STCPreset
•0—100%
ResetAdvanced
•Yes
•No
Adjustingtheradartunecontrol
Fromtheradarapplication:
1.SelectMenu.
2.SelectScannerSet-up.
3.SelectTuneAdjust.
4.SelectTuneAdjust.
SelectingTuneAdjustwillswitchthefunctionbetweenAuto
andMan.
5.InManualmodeusetheRotaryControltoadjustthelevel,to
obtainthemaximumsignalstrength(indicatedbytheeight-step
horizontalbar).
144
e7/e7D/e95/e97/e125/e127/c95/c97/c125/c127
