DatapageDefaultDataItems
Engine2
•OilPressure1
•CoolantTemperature1
•CoolantTemperature2
•OilPressure2
•RPM1
•TrimTabs
•RPM2
•TotalFuel
•Rudder
•SOG
Engine3
•CoolantTemperature1
•CoolantTemperature2
•CoolantTemperature3
•RPM1
•RPM2
•RPM3
•TotalFuel
•Rudder
•SOG
Note:Datapageselectionisalocalsetting,andthereforeonly
affectstheindividualdisplaythatyouarecurrentlyusing.Itdoes
notaffectanynetworkeddisplays.
15.3Customizingthedataapplication
Youcancustomizethedataapplicationtoshowthesystemand
instrumentdatathatyourequire.
Inadditiontodisplayingthedefault,pre-congureddatapagesinthe
dataapplication,youcanalso:
•Changetheorderdatapagesappear.
•Customizedatapagescontenttoyourspecicrequirements.
•Renamethedatapages.
•Addnewcustomdatapages.
•Deleteexistingdatapages.
•Setthenumberofenginesyourvesselhas(1—3).
•SetthemaximumengineRPMrange.
•Changepagecolorthemeanddialcolor.
•Resetallpagestodefault.
Changingdatapageorderusingtouch
Youcanchangetheorderthatdatapagesappear.
ThisonlyappliestoHybridTouchdisplays.
Fromthedataapplication:
1.Scrolltothedatapageyouwanttomove.
2.SelectMenu.
3.SelectEditPage.
Theeditpagemenuisdisplayed.
4.SelectMovePageUporMovePageDown.
Eachtimemovepageupormovepagedownisselected
thedatapagewillbemoved1spaceupordowninthedata
application.
Changingdatapageorder
Youcanchangetheorderthatdatapagesappear.
Fromthedataapplication:
1.UsingtheRotaryControlorJoystickscrolltothedatapage
youwanttomove.
2.SelectMenu.
3.SelectEditPage.
Theeditpagemenuisdisplayed.
4.Tomoveadatapageup:
i.SelectMovePageUp.
ii.PresstheOkbuttontoconrm.
5.Tomoveadatapagedown:
i.SelectMovePageDown.
ii.PresstheOkbuttontoconrm.
Eachtimemovepageupormovepagedownisselectedand
conrmedthedatapagewillbemoved1spaceupordowninthe
dataapplication.
Customizingdatapagecontent
Fromthedataapplication:
1.SelectMenu.
2.SelectEditPage.
3.Selectthecellyouwanttochange.
4.SelectSelectDataCategory.
5.Selectadatacategory.
Selectingadatacategorywilldisplayalistofdataitemsfor
thatcategory.
6.Selectthedataitemyouwanttodisplay.
Onceselectedatickwillbeplacednexttothedataiteminthe
menuandthecellonscreenwilldisplaythenewdataitem
7.Repeatsteps3to6forallthedataitemsyouwanttochange.
Listofdataitems
Dataitemscanbedisplayedindatapagecells.
Thefollowingtableshowsthedataitemsavailablebycategory.
Usingthedataapplication
175
