Raymarine Micro-Talk E70361 - Document Information; Applicable Products; Product Documentation; Document Illustrations

2.1Documentinformation
Thisdocumentcontainsimportantinformationrelated
totheinstallationofyourRaymarineproduct.
Thedocumentincludesinformationtohelpyou:
•planyourinstallationandensureyouhaveallthe
necessaryequipment;
•installandconnectyourproductaspartofawider
systemofconnectedmarineelectronics;
•troubleshootproblemsandobtaintechnicalsupport
ifrequired.
ThisandotherRaymarineproductdocuments
areavailabletodownloadinPDFformatfrom
www.raymarine.com.
Applicableproducts
Thisdocumentisapplicabletothefollowingproducts:
Part
numberNameDescription
E70361Micro-TalkMicronet
(Wireless)to
SeaTalkng®
gateway
Productdocumentation
Thefollowingdocumentationisapplicabletoyour
product:
Description
Part
number
Micro-TalkInstallationinstructions
InstallationofaMicro-Talkgatewayand
connectiontoawidersystemofmarine
electronics.
87265/
88066
Micro-Talkmountingtemplate
TemplateforsurfacemountingtheMicro-Talk
gateway.
87272
Documentillustrations
Yourproductmaydifferslightlyfromthatshowninthe
illustrationsinthisdocument,dependingonproduct
variantanddateofmanufacture.
Allimagesareprovidedforillustrationpurposesonly.
Operationinstructions
Fordetailedoperationinstructionsforyourproduct,
refertothedocumentationthataccompaniesyour
display.
2.2Productoverview
TheMicro-TalkgatewaybridgesdatabetweenMicronet
(wireless)andSeaTalkng®networks.Whenusedin
conjunctionwithaSeaTalk®toSeaT alkng®converter
thedatacanalsobebridgedontotheSeaT alk®
networkordevices.
TheMicro-Talkgatewayhasthefollowingfeatures:
•BridgesdatafromMicronettoSeaT alkng®
•BridgesdatafromSeaTalkng®toMicronet
•Pole,RailorSurfaceorBracketmountableusing
optionalmountingkits
•NMEA2000compliant
•Lowpowerconsumption
•12Vdcoperation(24Vprotection)
•WaterprooftoIPx6andIPx7
ThefollowingdatacanbebridgedbytheMicro-T alk
gateway:
Data
Micro-Talkto
SeaTalkng®
SeaTalkng®to
Micro-Talk
Wind
Mastrotation
Depth
(1)
or
(2)
10
