ConnectingSeaTalkng®cables
1.Rotatethelockingcollarontheunittotheunlocked
position.
2.Ensurethecable’sconnectoriscorrectlyoriented.
3.Fullyinsertthecableconnector.
4.Rotatelockingcollarclockwise(2clicks)untilitisin
thelockedposition.
SeaTalkng®productloading
Thenumberofproductsthatcanbeconnectedto
aSeaT alkng®backbonedependsonthepower
consumptionofeachproductandthephysicaloverall
lengthofthebackbone.
SeaTalkng®productshaveaLoadEquivalency
Number(LEN),whichindicatestheproduct’spower
consumption.TheLENforeachproductcanbefound
intheproduct’sTechnicalSpecication.
4.3SeaTalkng®powersupply
PowerissuppliedtotheproductovertheSeaTalkng®
backbone.
ASeaT alkng®backbonerequiresone12Vdcpower
supply,connectedtotheSeaT alkng®backbone.This
canbeprovidedby:
•abattery
(1)
,viathedistributionpanel,
•anAutopilotControlUnit(ACU)
(2)
,
•anSPXcoursecomputer
(2)
,
•for24Vvesselsa5amp,regulated,continuous24V
dcto12Vdcconverterisrequired.
Note:
•(1)Thebatteryusedforstartingthevessel’s
engine(s)shouldNOTbeusedtopowerthe
SeaTalkng®backboneasthiscancausesudden
voltagedrops,whentheenginesarestarted.
•(2)TheACU-100andSPX-5cannotbeusedto
powertheSeaTalkng®backbone.
SeaTalkng®powerconnectionpoint
Smallsystems
Ifthebackbonelengthis60m(197ft)orless,the
powerconnectionpointmaybeconnectedatanypoint
inthebackbone.
Largesystems
Ifthebackbonelengthisgreaterthan60m(197ft),
thepowerconnectionpointshouldbeconnectedata
pointthatcreatesabalancedcurrentdrawfromeach
sideofthebackbone.TheLoadEquivalencyNumber
(LEN)isusedtodeterminethepowerconnectionpoint
forthesystem.
IntheexampleabovethesystemhasanoverallLENof
10,sotheoptimumconnectionpointwouldbetohave
5LENeithersideoftheconnectionpoint.
In-linefuseandthermalbreaker
ratings
TheSeaT alkng®network’spowersupplyrequiresan
in-linefuseorthermalbreakertobetted.
In-linefuseratingThermalbreakerrating
5A
3A(ifonlyconnectingone
device)
Note:Thesuitablefuseratingforthethermal
breakerisdependentonthenumberofdevicesyou
areconnecting.Ifindoubtconsultanauthorized
Raymarinedealer.
Cablesandconnections19
