10.1Accessories
Thefollowingaccessoriesareavailable:
Accessories
ItemPartnumber
Pole/railmountingadaptorkit
A80370
6mSeaTalkngwhitespur
cable
A06072
Deckmounting
(Clamshell/Riser)kit
A80437
10.2SeaTalk
ng®
cabling
components
SeaTalk
ng
cablingcomponentsandtheirpurposes.
Connection/CableNotes
Backbonecable(various
lengths)
Themaincablecarryingdata.
Spursfromthebackboneare
usedtoconnectSeaTalk
ng
devices.
T-piececonnectorUsedtomakejunctionsinthe
backbonetowhichdevices
canthenbeconnected.
Terminator
Requiredateitherendofthe
backbone.
InlineterminatorUsedtoconnectaspur
cabledirectlytotheendofa
backbone;usefulforlonger
cableruns.
Spurcable
Usedtoconnectdevices
tothebackbone.Devices
maybedaisychainedor
connecteddirectlytothe
T-pieces.
SeaTalk
ng
5–wayconnector
Usedtobranch,split,or
makeadditionalconnections
inSeaTalkorSeaT alk
ng
networks.
BlankingplugInsertedintounusedspur
connectorpositionsina
5-wayconnectororT-piece.
10.3SeaTalk
ng®
cablesand
accessories
SeaTalk
ng
cablesandaccessoriesforusewith
compatibleproducts.
DescriptionPartNoNotes
SeaTalk
ng
starterkit
T70134Includes:
•1x5Wayconnector
(A06064)
•2xBackboneterminator
(A06031)
•1x3m(9.8ft)spur
cable(A06040)
•1xPowercable
(A06049)
SeaTalk
ng
BackboneKit
A25062Includes:
•2x5m(16.4ft)
Backbonecable
(A06036)
•1x20m(65.6ft)
Backbonecable
(A06037)
•4xT-piece(A06028)
•2xBackboneterminator
(A06031)
•1xPowercable
(A06049)
SeaTalk
ng
0.4m
(1.3ft)spur
A06038
SeaTalk
ng
1m
(3.3ft)spur
A06039
SeaTalk
ng
3m
(9.8ft)spur
A06040
