Moreinformation
Raymarinerecommendsthatbestpracticeisobserved
inallvesselelectricalinstallations,asdetailedinthe
followingstandards:
•BMEACodeofPracticeforElectricalandElectronic
InstallationsinBoats
•NMEA0400InstallationStandard
•ABYCE-11AC&DCElectricalSystemsonBoats
•ABYCA-31BatterychargersandInverters
•ABYCTE-4LightningProtection
Sharingabreaker
Wheremorethan1pieceofequipmentsharesa
breakeryoumustprovideprotectionfortheindividual
circuits.E.g.byconnectinganin-linefuseforeach
powercircuit.
1
Positive(+)bar
2
Negative(-)bar
3
Circuitbreaker
4Fuse
Wherepossible,connectindividualitemsofequipment
toindividualcircuitbreakers.Wherethisisnotpossible,
useindividualin-linefusestoprovidethenecessary
protection.
Warning:Product
grounding
Beforeapplyingpowertothisproduct,
ensureithasbeencorrectlygrounded,in
accordancewiththeinstructionsprovided.
Warning:Positiveground
systems
Donotconnectthisunittoasystemwhich
haspositivegrounding.
4.4Networkexamples
Theillustrationsbelowareprovidedasexamplesonly.
Examplesystemwithwirelesshulltransmitter
1.Mastrotationsensor
2.MicronetWindVane
3.Micro-Talkgateway
4.Wirelessinstrument
5.SeaTalkng®instrument
6.SeaTalkPilotController
7.SeaTalkng®MFD
8.SeaTalktoSeaT alkng®converter
9.T909Compasstransducer
10.Wirelesshulltransmitter
Cablesandconnections
