3.5Displaysettings
Displayandsharedbrightness
Youcanchangethebrightnessoftheindividualdisplay,or
networkeddisplays.
Youcanonlyuseandsetsharedbrightnessondisplayswhich
supportsharingandareassignedtonetworkgroups.
Youwillnotbeabletosetsharedbrightnesslevelsondisplays
whichdonotsupportsharing.
Adjustingthedisplaysbrightness
Toadjustthebrightnessoftheindividualdisplay:
1.WhilstinafavoritepagemomentarilypresstheLEFTSOFT
button.
Thiswillopenthebrightnesssettingscreen.
2.UsetheUPandDOWNbuttonstochangethebrightness
percentagetotherequiredlevel.
3.PresstheRIGHTSOFTbuttontoconrmnewbrightnessandgo
backtothefavoritespageyouwereon.
AssigningANetworkGroup
Whenassignedtoanetworkgroupyoucanchangebrightnesslevel
andcolorschemeondisplayswhichsupportsharing.
Toenablesharedbrightnessandcolorschemesthedisplaymust
beassignedtoanetworkgroupasfollows:
1.NavigatetoMenu>SetUp>SystemSetUp>NetworkGroup.
Alistofnetworkgroupswillbedisplayed:
•None(default)
•Helm1
•Helm2
•Cockpit
•Flybridge
•Mast
•Group1—Group5
2.UsetheUPandDOWNbuttonstohighlighttherequiredgroup.
3.PresstheSELECTbuttontoassignthedisplayyouareusing
tothatnetworkgroup.
4.NavigatetoMenu>SetUp>SystemSetUp>
Brightness/ColourGroup.
Youwillbepresentedwiththefollowingoptions:
•ThisDisplay
•ThisGroup
5.Highlightandselecttherequiredsetting.
6.Carryoutsteps1to5onalldisplaysyouwishtoshare.
Adjustingthesharedbrightness
Sharedbrightnessisonlyaccessibleifthedisplayhasbeen
assignedtoanetworkgroup.
1.WhilstonafavoritespagepresstheLEFTSOFTbuttonto
displaythebrightnesssetting.
2.PresstheLEFTSOFTbuttonagaintoaccesstheshared
brightnesssettings.
3.UsetheUPandDOWNbuttonstochangethesharedbrightness
level.
DisplayandsystembrightnesscanalsobeaccessedviaMenu>
Displaysettings>Brightness.
Displayandsharedcolor
Thep70/p70rcansetacolorschemefortheindividualdisplayor
forthesystem(ifcolorisavailableonthenetworkdisplays).
ColorsettingscanbeaccessedviaMenu>Displaysettings>
Colors.
Colorschemesavailableare:
Gettingstarted
19

Raymarine p70r Specifications

General

Display Type	LCD
Resolution	320 x 240 pixels
Waterproof Rating	IPX6
Connectivity	SeaTalkng
Operating Temperature	-15°C to +55°C
Type	Autopilot Control Unit
Compatibility	Raymarine Autopilot Systems
Display Size	3.5 inches
Operating Voltage	10-32V DC
