Raymarine p70r User Reference

e.g.pressingthe-1buttonfourtimes,orturningtherotary4clicks
anticlockwisewillresultina4°coursechangetoport.
5.3Modepage
Themodepageistheinitialscreendisplayedaftersetupofthe
device.Ifthedeviceisbeingswitchedonforthersttime,theuser
istakentotheinitialSetupwizard.Oncethedevicehasbeenset
uptheywillthenproceedtotheModepage.Themodepageisused
toshowwhatmodeyouareinandalsorelevantpilotinformation
forthatmode.
Theselectionofvesseltypeduringtheinitialsetupdetermines
whichproleandmenustructurethepilotwillbesetto(e.g.Power,
shingorsailingboat):
Themodesavailablewilldependonthevesseltypechosenduring
initialsetup.
•Pattern1—Fishingboatonly(thiswilltakeyoutothemost
commonpatternforthelast10selections.
•Pattern2—Fishingboatonly(thiswilltakeyoutothesecond
mostcommonpatternforthelast10selections.
•Pattern—Powerandshingboatsonly.
•Track—allproles.
•Windvane—sailingboatonly.
•Powersteer—allproles(p70rrotarycontrollerandjoystickonly).
•Shortcutkey-allowsyoutosetwhichpilotmodeismappedtothe
leftsoftbuttonwheninpilotview.
Pilotmodes31

Raymarine p70r Specifications

General

Display Type	LCD
Resolution	320 x 240 pixels
Waterproof Rating	IPX6
Connectivity	SeaTalkng
Operating Temperature	-15°C to +55°C
Type	Autopilot Control Unit
Compatibility	Raymarine Autopilot Systems
Display Size	3.5 inches
Operating Voltage	10-32V DC
