9.7 Jog steer (tiller pilots only)
If you have a tiller drive installed on a SeaTalk
network, your vessel you can use the pilot controller
to operate the ram in Jog steer mode.
Jog steer mode enables you to use the pilot
controllers –1, +1, –10, +10 buttons, or the ROTARY
controller to move the ram in and out to aid
connecting and disconnecting the ram.
Note: Jog Steer can only be used whilst your
vessel is in STANDBY.
Using jog steer (tiller drives only)
1. Ensure your vessel pilot is in STANDBY mode.
2. Use the –1 and –10 buttons, or turn the rotary
controller anticlockwise to retract the ram.
3. Use the +1 and +10 buttons, or turn the rotary
controller clockwise to extend the ram.
9.8 Shortcut key
When in pilot view you can assign pilot modes to
the LEFT SOFT button as a shortcut depending on
which vessel type has been set up.
The following pilot modes can be assigned as
shortcuts:
• Track (default) — All vessels
• Pattern — Power and shing vessels
• Power steer — All vessels (Rotary only)
• Wind vane — Sailing vessels
Assigning the shortcut key
In order to assign a pilot mode as a shortcut mapped
to the LEFT SOFT button follow the steps below:
1. Navigate to the Shortcut menu: Menu > Mode >
Shortcut.
2. Select the required pilot mode.
3. Press SAVE.
Pilot modes 67

Raymarine p70r Specifications

General

Display Type	LCD
Resolution	320 x 240 pixels
Waterproof Rating	IPX6
Connectivity	SeaTalkng
Operating Temperature	-15°C to +55°C
Type	Autopilot Control Unit
Compatibility	Raymarine Autopilot Systems
Display Size	3.5 inches
Operating Voltage	10-32V DC
