Raymarine REALVISION 3D RV-3 Series User Manual

2.2Applicableproducts
ThisdocumentisapplicabletotheR
V-300,RV-312(P/S),andRV-320(P/S)RealVision™3Dplastic
thru-hulltransducers.
Thesetransducersarecapableofproducing3DsonarimageswhenconnectedtoaRealVision™
3DvariantMFDrunningLightHouse™3software,oraLightHouse™3compatibleMFDusedin
conjunctionwithanRVX1000RealVision™3Dsonarmodule.Fivetransducersareavailableinthe
RV-3xxseries,eachhavingthesameexternalshapeanddimensions.
Important:
•Plasticthru-hulltransducersarerecommendedforfiberglassandmetalhullsandshouldnotbe
usedonvesselswithawoodenhull.
Thetransducersdifferinternally ,andcontaindifferentnumbersandtypesoftransmitandreceive
elements.YourinstallationshouldcompriseeitherasingleRV-300transducer,orasplit-pairof
RV-312(P/S)orRV-320(P/S)transducers.
Thehullgeometryofyourvesseldeterminesthemostappropriatetransducerstouse.Youshould
fittransducerswhoseinternalelementsarematchedtowithin±6°ofyourhull’sdeadriseangle,as
showninthefollowingtable:
Modelno .
System
packPartno.DescriptionHullgeometry
R V-300
N/A
A80470
PlasticThru-Hull
Transducer,0°,single
(“allinone”)
Hullwith0°(flat-bottom)to6°deadrise
angle.
R V-312PA80471Hullwith6°to18°deadriseangle,port
side.
R V-312S
T70320
A80472
PlasticThru-Hull
Transducer,12°,split-pair
Hullwith6°to18°deadriseangle,
starboardside.
R V-320PA80473Hullwith14°to26°deadriseangle,
portside.
R V-320S
T70321
A80474
PlasticThru-Hull
Transducer,20°,split-pair
Hullwith14°to26°deadriseangle,
starboardside.
Documentandproductinformation
13
