2.5P
artssupplied—RV-3xxseriestransducers
ThefollowingpartsaresuppliedwithallRV-3xxseriestransducervariants.
ItemDescriptionQuantity
1
T ransducer(includingcable)
1
2
Anti-rotationnut1
3Smallwasher
1
4Anti-rotationbolt1
5Anti-rotationboltcap1
6
Hullnut1
7
Cableprotector
1
8Spacer
1
9
Rubberwasher1
10
Documentationpack1
11
L ockingcollarkit(fortransducercableconnector),consisting
of:
•2xSplitrings(includesspare)
•1xO-ring
•1xLockingcollar
•1xSplitringfittingtool
1
16
