•Theproductissuppliedfromaseparatebatteryfromthatusedforenginestart.Thisisimportant
topreventerraticbehavioranddatalosswhichcanoccuriftheenginestartdoesnothavea
separatebattery
.
•Raymarinespecifiedcablesareused.
•Cablesarenotcutorextended,unlessdoingsoisdetailedintheinstallationmanual.
Note:
Whereconstraintsontheinstallationpreventanyoftheaboverecommendations,alwaysensure
themaximumpossibleseparationbetweendifferentitemsofelectricalequipment,toprovidethe
bestconditionsforEMCperformancethroughouttheinstallation.
T ransducerdimensions—RV-3xx
AlltransducersintheRV-3xxserieshavethesameexternaldimensions.
ItemMeasurement
A
8.0mm(0 .31in.)
B
90 .72mm(3.57in.)
C
23.0mm(0 .90in.)
D
60 .0mm(2.36in.)
E
35.0mm(1.4in.)
F
80 .0mm(3.15in.)
G
136mm(5.35in.)
H
31.0mm(1.22in.)
I
170mm(6.69in.)
J
85.0mm(3.35in.)
K
308.0mm(12. 13in.)
Installation25
